dji MATRICE 200

Using Matrice 200
1. Download the DJI Assistant 2 and DJI GO 4 App
Download and install DJI ASSISTANT
TM
2 on your computer via the website link below:
http://www.dji.com/matrice-200-series
Search ‘DJI GO 4’ in the App Store or Google Play, and download the app to your mobile device.
First-time activation requires your DJI account and internet connection.
Internet
DJI GO 4 app supports iOS 9 (or later) or Android 4.4 (or later).
If using a DJI CrystalSky
TM
Monitor, it is recommended to use the built-in DJI Pilot app.
DJI Assistant 2 supports Windows 7 (or later) or OS X 10.11 (or later).
DJI GO 4 App
2. Charge the Batteries
The Intelligent Flight Battery must be fully charged before using it for the rst time. Be sure to press the release button on the top of the
Charging Hub when removing the fully charged battery.
When charging is complete, the LED lights on the Intelligent Flight Battery will turn off, and the LED on the Charging Hub will show green.
Power off the remote controller before charging. When charging is complete, the LED lights on the remote controller will turn off.
The Charging Hub will sound a signal when the battery has been fully charged. The sound can be turned on or off by toggling the switch at
the bottom of the hub.
Install the battery to the aircraft and power on. Once the battery temperature is lower than 15℃, it will auto heat to maintain a temperature
between 15-20℃.
Pairing batteries is recommended. This can be done inside the DJI GO 4 app. Ensure each battery pair is charged and discharged
simultaneously to prolong their service life and for a better ight experience.
Press the release button and open the corresponding charging port cover.
Insert the Intelligent Flight Battery into the charging port to begin charging.
B
A
B
A
2
1
Power Outlet
100-240V
(50Hz/60Hz)
Charging Time: 1.5 hours* Charging Time: 3 hours*
* Provided charger
3. Prepare the Remote Controller
Unfold the mobile device holder and the antennas.
Press the power button once to check the battery level.
Press the button to
release the clamp.
Unfold
Low
High
Place your mobile
device and adjust
the clamp to secure.
Connect your mobile
device with a USB cable.
1
3
2
Strong Weak
