dji MAVIC PRO

Remote Controller
Mavic Pro User Manual
32
©
2016 DJI All Rights Reserved.
Charger
Power Outlet
Controlling the Camera
Shoot videos/photos, and adjust camera settings via the Shutter Button, Record Button, and Camera Set-
tings Dial on the remote controller.
1
.
Camera Settings Dial
Turn the dial to adjust camera settings such as ISO, shutter speed, without letting go of the remote
controller.
2. Shutter Button
Press to take a photo. If burst mode is activated, multiple photos will be taken with a single press.
3. Record Button
Press once to start recording video, then press again to stop recording.
4. Gimbal Dial
Control the tilt of the gimbal.
Controlling the Aircraft
This section explains how to control the orientation of the aircraft through the remote controller. The
Remote Control is set to Mode 2 by default.
Stick Neutral/Mid-Point: Control sticks are in the center position.
Moving the Control Stick: The control stick is pushed away from the center position.
1
2
3
4
