Using Virtual Joysticks
Ensure the mobile device has been connected to the aircraft before using the Virtual Joysticks. The
illustrations below are based on Mode 2 (left stick as throttle).
AE
09:29
61%
P-GPS
12
READY TO GO (GPS)
Virtual Joysticks GUI
Left Right
Move the aircraft upwards, downwards or rotate to the left or right by pressing on the left half of the
screen. Move the aircraft forwards, backwards or rotate to the left or right by pressing on the right half of
the screen.
Tap on the " " button to enable or disable Virtual Joysticks.
Launch the DJI GO app and tap the icon on the top right of your screen, then scan the
Wi-Fi QR Code on the front arm to start connection. Note that this feature is available on
Android devices.
When using Wi-Fi in a wide open area with no Electromagnetic Interference, transmission
distance is approximately 262ft (80m) at an altitude of 164ft (50m). The maximum ight
speed is 9mph (14kph), maximum ascent speed is 2m/s and maximum descent speed is
1m/s.
The Wi-Fi frequency of your mobile device can be set to 2.4GHz (default) or 5GHz. On
supported devices, set Wi-Fi to 5GHz for less interference.
Press and hold the linking button for 5 seconds or more to set Wi-Fi password and SSID.
Press and release to rest the transmission frequency to 2.4 GHz.
The area beyond the white cycle is also responsive to control commands.
