dji MIC User Manual

2. Battery Level Indicators
Indicates the charging status.
Specifications
Name DJI MIC Transmitter
Model
AST01
Dimensions
47.32
×
30.43
×
20.01 mm
Weight
30 g
Power Consumption
200 mW
Wireless Mode
GFSK 1Mbps and 2Mbps
Transmitter Power（EIRP）
17.5dBm
Operating Frequency 2400-2483.5 MHz
Charging Temperature 5℃-45℃
Operating Temperature -10℃-45℃
Name
DJI MIC Receiver
Model
ASR01
Dimensions
47.44
×
32.21
×
17.35 mm
Weight
24.9 g
Power Consumption
200 mW
Wireless Mode
GFSK 1 Mbps and 2M bps
Transmitter Power（EIRP）
18.5 dBm
Operating Frequency
2400-2483.5 MHz
Charging Temperature
5℃-45℃
Operating Temperature
-10℃-45℃
Name
Charging Case
Model
ASB01
Dimensions
103.06
×
61.87
×
41.50 mm
Weight
162.2 g
Charging Temperature
5℃-45℃
Operating Temperature
5℃-45℃
Safety at a Glance
Please read this entire document and visit https://www.dji.com/mic to view the user
manual, other documents, and the tutorial videos with the most current instructions and
warnings. Failure to read and follow instructions and warnings may result in personal injury,

dji MIC Specifications

General

Battery Life	5.5 hours
Dimensions	47.3 × 30.4 × 20.0 mm
Weight	30 g
Connections	USB-C, 3.5mm TRS
Battery Capacity	320 mAh
Operating Frequency	2.4 GHz
Frequency Response	20 Hz to 20 kHz
Operating Range	250 m (open area)
Compatibility	Cameras, Smartphones
Frequency Range	2400 to 2483.5 MHz
Operating Distance	250 m (open area)
Power Supply	Built-in Battery
Audio Input	3.5mm TRS
