dji OM 4 User Manual

16
© 2020 DJI OSMO All Rights Reserved.
Firmware Update
Use DJI Mimo to update the DJI OM 4 firmware. It takes approximately three minutes to
complete an update.
How to Update
Before starting an update, make sure that the battery level is at least 15% (at least two battery
level indicators illuminated). Connect DJI OM 4 to your mobile device and launch DJI Mimo.
You will be prompted if a new rmware update is available. To start updating, connect the
mobile device to the internet and follow the on-screen instructions.
Do not exit DJI Mimo while updating the rmware. Pay attention to on-screen prompts. The
system status indicator will blink green and red alternatively and become solid green once
the rmware update has completed successfully.
If an update is unsuccessful, restart DJI OM 4 and DJI Mimo, reconnect the Bluetooth, and
retry.
Storage
DJI OM 4 is designed to be folded for easier storage and transportation. Make sure to fold
DJI OM 4 when it is powered off.
Rotate the pan and tilt axis to align with the marks on the gimbal and fold DJI OM 4. Note that
the hole on the pan motor should be matched with the marker on the arm. DJI OM 4 will enter
storage mode and can be folded after powering off.

dji OM 4 Specifications

General

Stabilization	3-Axis
Battery Life	15 hours
Weight	390 g
Compatible Devices	Smartphones
Mounting	Magnetic phone clamp
App	DJI Mimo
Compatible Phone Weight	230 ± 60 g
Compatible Phone Thickness	6.9 - 10 mm
Compatible Phone Width	67 - 84 mm
Battery Capacity	2450 mAh
Battery Energy	17.64 Wh
Battery Voltage	7.2 V
Charging Time	2.5 hours
Gimbal Charging Port	USB-C
External Device Charging Port	USB-A
Universal Mount	1/4"-20 UNC port
Wireless	Bluetooth 5.0
Gimbal Controllable Range	Pan: -161.2° to 171.95°, Roll: -136.7° to 198°, Tilt: -106.54° to 235.5°
Max Controllable Speed	120°/s
Max Payload	290 g
Dimensions Folded	163 × 99.5 × 46.5 mm
Battery Type	Li-ion
Dimensions Unfolded	276 × 119.6 × 103.6 mm (L×W×H)
