dji OM 4 User Manual

© 2020 DJI OSMO All Rights Reserved.
17
Specications
Name DJI OM 4
Model OK100
Dimensions
Unfolded: 276×120×104 mm
Folded: 163×100×47 mm
Weight
390 g (gimbal)
32.6 g (magnetic phone clamp)
11.4 g (magnetic ring holder)
Power Consumption 1.2 W (steady and balanced status)
Mechanical Range
Pan: -161.2° to 172°
Roll: -136.7° to 198°
Tilt: -106.5° to 235.5°
Max Controllable Speed 120°/s
Compatible Phones
Using Magnetic Phone Clamp and Ring Holder:
Weight: 230±60 g
Using Magnetic Phone Clamp:
Diagonal: ≤ 196 mm (or ≤ 7.72 in)
Thickness: 6.9-10 mm
Width: 67-84 mm
Wireless Mode Bluetooth Low Energy 5.0
Transmission Power (EIRP) ≤4 dbm
Operating Frequency 2.400-2.4835 GHz
Battery Type 18650 Li-ion
Capacity 2450 mAh
Energy 17.64 Wh
Voltage 7.2 V
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Charging Time
2.5 hours (Measured with a 10W charger in the environment
temperature of 25° C)
Operating Time
15 hours (Under ideal conditions with the gimbal fully
balanced)

dji OM 4 Specifications

General

Stabilization	3-Axis
Battery Life	15 hours
Weight	390 g
Compatible Devices	Smartphones
Mounting	Magnetic phone clamp
App	DJI Mimo
Compatible Phone Weight	230 ± 60 g
Compatible Phone Thickness	6.9 - 10 mm
Compatible Phone Width	67 - 84 mm
Battery Capacity	2450 mAh
Battery Energy	17.64 Wh
Battery Voltage	7.2 V
Charging Time	2.5 hours
Gimbal Charging Port	USB-C
External Device Charging Port	USB-A
Universal Mount	1/4"-20 UNC port
Wireless	Bluetooth 5.0
Gimbal Controllable Range	Pan: -161.2° to 171.95°, Roll: -136.7° to 198°, Tilt: -106.54° to 235.5°
Max Controllable Speed	120°/s
Max Payload	290 g
Dimensions Folded	163 × 99.5 × 46.5 mm
Battery Type	Li-ion
Dimensions Unfolded	276 × 119.6 × 103.6 mm (L×W×H)
