dji OM 4 User Manual

© 2020 DJI OSMO All Rights Reserved.
9
DJI OM 4
User Manual
Zoom Slider
Move the slider to the T position to enlarge the subject and move the slider to
the W position to shrink. Push the slider once to change the zoom once. Push
the slider continuously to change the zoom continuously.
Trigger
Press and hold to enter lock mode. In lock mode, the gimbal will not follow the
handle movements. Release to exit lock mode.
Press once to start or stop ActiveTrack 3.0.
Press twice to recenter the gimbal. When using ActiveTrack 3.0, the gimbal
will recenter to the center of the camera view.
Press three times to switch between front and back cameras.
Press once, and then press and hold to enter Sport mode. Release to exit. In Sport
mode, the follow speed of the gimbal increases for capturing quick movements.
Combination Operation
The Bluetooth connection can be reset if DJI OM 4 cannot be connected or found. Press the
M button, shutter button, and trigger simultaneously to reset the Bluetooth connection. The
Bluetooth connection is reset successfully when the system status indicator turns from green
to yellow. Search DJI OM 4 and reconnect.
DJI OM 4 will be powered off automatically if there is no operation for 10 minutes in
standby mode.
Charging Port (USB-C)
Charge DJI OM 4 by connecting a USB adapter to this port.
USB-A Port
The USB-A port can be used to charge mobile phones.
1/4”-20 UNC Port
The 1/4"-20 UNC port can be used to attach a tripod.
Lanyard Hole
The lanyard hole can be used to attach a wrist strap.
M3×0.5 Screw Hole
Used to mount counterweights. Counterweights should be used if a camera
lens or microphone is mounted on the mobile phone. Make sure the total
weight of these accessories is less than 290 g.

dji OM 4 Specifications

General

Stabilization	3-Axis
Battery Life	15 hours
Weight	390 g
Compatible Devices	Smartphones
Mounting	Magnetic phone clamp
App	DJI Mimo
Compatible Phone Weight	230 ± 60 g
Compatible Phone Thickness	6.9 - 10 mm
Compatible Phone Width	67 - 84 mm
Battery Capacity	2450 mAh
Battery Energy	17.64 Wh
Battery Voltage	7.2 V
Charging Time	2.5 hours
Gimbal Charging Port	USB-C
External Device Charging Port	USB-A
Universal Mount	1/4"-20 UNC port
Wireless	Bluetooth 5.0
Gimbal Controllable Range	Pan: -161.2° to 171.95°, Roll: -136.7° to 198°, Tilt: -106.54° to 235.5°
Max Controllable Speed	120°/s
Max Payload	290 g
Dimensions Folded	163 × 99.5 × 46.5 mm
Battery Type	Li-ion
Dimensions Unfolded	276 × 119.6 × 103.6 mm (L×W×H)
