dji OSMO MOBILE 2 Quick Start Guide

5
EN
3. Mounting and Balancing a Mobile Phone
Make sure to only mount and balance a mobile phone while
the Osmo Mobile 2 powered off.
Mount the Mobile Phone Horizontally
Place the mobile phone in the mobile phone holder while
pulling out the holder. It is recommended to keep the
mobile phone close to the right.
Adjust the position of the mobile phone holder. The tilt axis
is balanced if the mobile phone remains still when released.
The Osmo Mobile 2’s USB port is capable of charging mobile
phones.
The Osmo Mobile 2 cannot charge mobile phones while
charging itself. Do not connect the USB port to a mobile phone
while the Osmo Mobile 2 is charging.
Connect the USB port to your mobile phone using a standard
Micro USB cable to start charging when the Osmo Mobile 2
is powered on. Press the Power/Mode button once to start
charging when the Osmo Mobile 2 is powered off.
1
2

dji OSMO MOBILE 2 Specifications

General

Dimensions	295 × 113 × 72 mm
Weight	485 g
Battery Life	up to 15 hours
Compatible Phones Width	58.6 - 84.8 mm
Battery Capacity	2600 mAh
Gimbal Range Pan	±160°
Gimbal Range Roll	±170°
Max Controllable Speed	120°/s
Max Payload	202 g
Type	Handheld Gimbal
Bluetooth	Bluetooth 4.0
Compatibility	iOS and Android smartphones
Operating Temperature	0° to 40° C
Charging Time	2 hours
Storage Temperature	-20° to 45°C
