dji OSMO MOBILE 2 Quick Start Guide

6
EN
The roll axis is balanced if the mobile phone remains level
when released.
Mount the Mobile Phone Horizontally
To mount the mobile phone vertically, loosen the Holder
Lock Knob and rotate the mobile phone holder for 90
degrees to mount and balance the mobile phone.
Hold the Osmo Mobile 2 horizontally, and then pull the
mobile phone until the mobile phone remains still when
released.
Left Right
If the roll axis tilts to the left,
pull out the arm until the roll
axis remains level.
1
2
1
2

dji OSMO MOBILE 2 Specifications

General

Dimensions	295 × 113 × 72 mm
Weight	485 g
Battery Life	up to 15 hours
Compatible Phones Width	58.6 - 84.8 mm
Battery Capacity	2600 mAh
Gimbal Range Pan	±160°
Gimbal Range Roll	±170°
Max Controllable Speed	120°/s
Max Payload	202 g
Type	Handheld Gimbal
Bluetooth	Bluetooth 4.0
Compatibility	iOS and Android smartphones
Operating Temperature	0° to 40° C
Charging Time	2 hours
Storage Temperature	-20° to 45°C
