dji OSMO MOBILE 3 User Manual

OSMO MOBILE 3 User Manual
Not nal
14
© 2019 DJI OSMO All Rights Reserved.
Specications
Name OSMO MOBILE 3
Model OF100
Dimensions
Unfolded: 285×125×103 mm
Folded: 157×130×46 mm
Weight 405 g
Consumption 1.2 W (steady and balanced status)
Mechanical Range
Pan: -162.5° to 170.3°
Roll: -85.1° to 252.2°
Tilt: -104.5° to 235.7°
Max Controllable Speed 120°/s
Compatible Phones
Weight: 200 ± 30 g
Dimension:
Diagonal ≤ 180 mm (or ≤ 7.08 in)
Thickness ≤ 9.5 mm
Width: 62-88 mm
Mode Bluetooth Low Energy 5.0
Transmitter Power (EIRP) ≤4 dBm
Operation Frequency 2.400-2.4835 GHz
Battery Type 18650 Li-ion
Capacity 2450 mAh
Energy 17.64 Wh
Voltage 7.2 V
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Maintenance
Osmo Mobile 3 is designed to be folded for easier storage and transportation. Ensure to fold the Osmo
Mobile 3 when it is powered o.
Rotate the pan and tilt axis to align with the marks on the gimbal, and then fold Osmo Mobile 3. Note
that the hole on the pan motor should be matched with the marker on the arm.
Press the M button to power o Osmo Mobile 3. Osmo Mobile 3 will enter storage mode and can be
folded.

dji OSMO MOBILE 3 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Functions	Panorama, Timelapse, Slow Motion, Sport Mode
Motorized	Yes
Product color	Gray
Number of axis	3
Maximum device depth	9.5 mm
Maximum device width	88 mm
Minimum device width	62 mm
Maximum weight capacity	0.23 kg
Charging time	2.5 h
Operating time	15 h
Battery voltage	7.2 V
Battery capacity	2450 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-162.5 - 170.3 °
Mechanical roll range	85.1 - 252.2 °
Mechanical tilt range	104.5 - 235.7 °
Bluetooth version	5.0
Cables included	USB

Weight and Dimensions

Depth	103 mm
Width	125 mm
Height	285 mm
Weight	405 g
Dimensions folded (WxDxH)	130 x 46 x 157 mm
