dji OSMO MOBILE 3 User Manual

OSMO MOBILE 3 User Manual
© 2019 DJI OSMO All Rights Reserved.
5
Getting Started
Charging
• To charge Osmo Mobile 3, connect a USB adapter (not included) to the charging port using the power
cable (included). The battery is fully charged when the battery level indicators turn off.
Charging time: 2.5 hours (when using a 10 W charger)
Max. runtime: 15 hours*
• Connect your mobile phone to the USB-A port. If Osmo Mobile 3 is powered on, the mobile phone will
begin to charge. If Osmo Mobile 3 is powered off, press the M button once to start charging.
Mounting and Balancing a Mobile Phone
Only mount and balance a mobile phone while Osmo Mobile 3 is powered o
.
• Make sure the phone holder is vertical before mounting a mobile phone.
• Hold the tilt motor and move the mobile phone left or right until the mobile phone remains balanced
when released.
USB-A Port
USB-C Charging Port
M Button
* Max. runtime was tested with the gimbal balanced and held steadily. This value should be taken as a
reference only.
If required, use the anti-slip pads (included) to secure the mobile phone in the phone holder.
Anti-Slip Pads

dji OSMO MOBILE 3 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Functions	Panorama, Timelapse, Slow Motion, Sport Mode
Motorized	Yes
Product color	Gray
Number of axis	3
Maximum device depth	9.5 mm
Maximum device width	88 mm
Minimum device width	62 mm
Maximum weight capacity	0.23 kg
Charging time	2.5 h
Operating time	15 h
Battery voltage	7.2 V
Battery capacity	2450 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-162.5 - 170.3 °
Mechanical roll range	85.1 - 252.2 °
Mechanical tilt range	104.5 - 235.7 °
Bluetooth version	5.0
Cables included	USB

Weight and Dimensions

Depth	103 mm
Width	125 mm
Height	285 mm
Weight	405 g
Dimensions folded (WxDxH)	130 x 46 x 157 mm
