dji OSMO MOBILE 3 Quick Start Guide

Shutter/Record Button:
Press once to start/stop recording or take a photo. Press and hold for burst capture.*
M Button
Tap once to switch between photo and video mode.
Tap twice to bring out shortcut menu (in this case, push the joystick to select from menu instead
of control gimbal attitude), tap once to exit menu.
Tap three times to switch between horizontal or portrait mode*.
Tap and hold to power on/off.
Push to zoom in or out.
*Horizontal and portrait mode can be switched by hand.
Tap and hold to enter lock mode, release to exit.
Tap once to start/stop ActiveTrack.
Tap twice to center the mobile phone.
Tap three times to switch between the mobile phone’s front and rear cameras.
Tap once and then hold to enter sport mode, release to exit.
* Mobile phone camera can be controlled by Osmo Mobile 3 without DJI Mimo after connecting
the Bluetooth of the mobile phone (mobile phone camera can be control by volume button).

dji OSMO MOBILE 3 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Functions	Panorama, Timelapse, Slow Motion, Sport Mode
Motorized	Yes
Product color	Gray
Number of axis	3
Maximum device depth	9.5 mm
Maximum device width	88 mm
Minimum device width	62 mm
Maximum weight capacity	0.23 kg
Charging time	2.5 h
Operating time	15 h
Battery voltage	7.2 V
Battery capacity	2450 mAh
Operating temperature (T-T)	0 - 40 °C
Mechanical pan range	-162.5 - 170.3 °
Mechanical roll range	85.1 - 252.2 °
Mechanical tilt range	104.5 - 235.7 °
Bluetooth version	5.0
Cables included	USB

Weight and Dimensions

Depth	103 mm
Width	125 mm
Height	285 mm
Weight	405 g
Dimensions folded (WxDxH)	130 x 46 x 157 mm
