9
OSMO+ User Manual
7JTJUUIFPGmDJBM%+*4UPSFIUUQTUPSFEKJDPNUPMFBSONPSF
Vehicle Mount
Triple suction cup mount makes it ideal for mounting on
top of or on the rear window of moving vehicles.
Straight Extension Arm
Used to attach up to three other mounts at the same time.
Unlocking the Gimbal
5PQSPUFDUUIFHJNCBMUIFNPUPSBYFTBSFMPDLFEJOQMBDF5PVOMPDLUIFHJNCBM
1. Gently rotate the roll motor until it can rotate freely.
Rotate the motor just enough to allow free motion.
2. Slide the Pan Axis Lock upwards to unlock the pan axis.
Pan Axis Lock
2
