dji Phantom 3 SE Quick Start Guide

EN
4
Using Phantom 3 SE
●
When charging is complete, the battery will automatically power o and the Status LED will change from red to green.
●
The DJI GO
TM
app supports iOS 8.0 and Android 4.1.2, or later versions.
2. Check the Battery Levels
3. Charge the Batteries
Press once to check the battery level.
Press once, then again and hold to turn on/o.
Remove the battery. Provided Charger
Charge Time: ~1.5 hours
USB Adapter Charge Time:
~2.5 hours (when charging at 1.5 A)
Power Outlet
100 - 240V
Low High Low High
1. Download the DJI GO App
Search 'DJI GO' on the App Store or Google Play and
download the app to your mobile device.
DJI GO App

dji Phantom 3 SE Specifications

General

Maximum speed	16 m/s
Number of axis	3
GPS (satellite)	Yes
Number of rotors	- rotors
Maximum flight time	25 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	4000 m
Operating temperature (T-T)	0 - 40 °C
Battery voltage	15.2 V
Battery capacity	4480 mAh
Certification	FCC, CE
Product color	White
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	30 fps
Camera shutter speed	8 - 1/8000 s
Supported video modes	720p, 1080p, 1520p, 2160p
Image formats supported	DNG, RAW
Video formats supported	AVC, H.264, MOV, MP4, MPEG4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	94 °
Bitrate at maximum video resolution	60 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Operating frequency	2400 - 2483; 5725 - 5825 MHz
AC adapter power	100 W
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Weight	1236 g
Battery weight	365 g
