dji Phantom 4 Advanced + User Manual

EN
5
●
Check that the propellers are secure before each ight.
First-time activation requires your DJI account and internet connection.
4. Prepare the Remote Controller
5. Prepare for Takeo
Unfold
Strong Weak
DJI GO
4 App
Remove the gimbal clamp from the
camera.
Black propeller rings go
on motors with black
dots.
Silver propeller
rings go on
motors without
black dots.
Press the propeller
down onto the
mounting plate and
rotate in the lock
direction until
secure.
Power on the remote controller and
the aircraft.
Complete rst-time setup
in DJI GO 4 and tap GO
FLY.
Internet

dji Phantom 4 Advanced + Specifications

General

Camera Sensor	1-inch CMOS
Effective Pixels	20 MP
Max Flight Time	Approx. 30 minutes
Max Descent Speed	4 m/s
Operating Temperature Range	0°C to 40°C
GPS Mode	GPS/GLONASS
Camera Max Video Bitrate	100 Mbps
Remote Controller Battery	6000 mAh LiPo 2S
Gimbal	3-axis (pitch, roll, yaw)
Battery Capacity	5870 mAh
Max Video Resolution	4K at 60fps
Max Speed	72 kph (Sport mode)
Transmission Range	7 km (FCC), 3.5 km (CE)
Obstacle Sensing System	Forward
Max Ascent Speed	6 m/s (Sport mode)
Camera Lens	FOV 84°, 8.8 mm (24 mm equivalent)
Camera ISO Range	100-3200 (video), 100-12800 (photo)
Camera Still Photography Modes	Single, Burst, Auto Exposure Bracketing, Interval
Camera Video Recording Modes	H.264
Gimbal Controllable Range	Pitch: -90° to +30°
Remote Controller Operating Frequency	2.400 - 2.483 GHz and 5.725 - 5.850 GHz
Remote Controller Max Transmission Distance	7 km (FCC), 3.5 km (CE)
Mobile Device Holder	Tablets and smartphones
Internal Storage	None (requires microSD card)
Remote Controller	Included (GL300E)
