dji Phantom 4 Pro V2.0 User Manual

Left stick down (slowly) until you touch the ground. Hold a few seconds to stop the motors.
Rotating propellers can be dangerous. Do not start the motors when there are people nearby.
Always keep your hands on the remote controller so long as the motor is still spinning.
Stop motor mid-flight: Pull the left stick to the bottom inside corner while simultaneously pressing the RTH button. Only
stop motors mid-flight in emergency situations when doing so can reduce the risk of damage or injury. Refer to the user
manual for details.
It’s important to understand basic flight guidelines, for the safety of both and those around you. Don’t forget to read
the Disclaimer and Safety Guidelines.
Specifications

dji Phantom 4 Pro V2.0 Specifications

General

Type	Quadcopter
Product color	White
Maximum speed	72 m/s
Frequency band	2.400 - 2.483/5.725 - 5.850 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum tilt angle	42 °
Maximum flight time	30 min
Maximum ascent speed	6 m/s
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.1 m
Horizontal hover accuracy	0.3 m
Maximum operating distance	7000 m
Built-in processor	-
Operating temperature (T-T)	0 - 40 °C
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1280 x 720, 1920 x 1080, 2720 x 1530, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1 \
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	84 °
Bitrate at maximum video resolution	100 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
AC adapter power	100 W
AC adapter input voltage	17.4 V
Battery voltage	15.2 V
Battery capacity	5870 mAh

Weight and Dimensions

Battery weight	468 g
Weight (including battery)	1375 g
