dji Phantom 4 Pro V2.0 User Manual

First-time activation requires your DJI account and internet connection.
Black propeller rings go on motors with black dots.
Silver propeller rings go on motors without black dots.
Press the propeller down onto the mounting plate and rotate in the lock direction until secure.
Check that the propellers are secure before each flight.
6. Flight
Ready to Go (GPS)
Before taking off, make sure the Aircraft Status Bar in the DJI GO 4 app indicates `Ready to Go (GPS)’ or `Ready to Go
(Vision)’ if flying indoors.
In the DJI GO 4 App:
Auto Takeoff The aircraft will take off and hover at an altitude of 4 feet (1.2 meters).
Auto Landing
The aircraft will land vertically and stop its motors.

dji Phantom 4 Pro V2.0 Specifications

General

Type	Quadcopter
Product color	White
Maximum speed	72 m/s
Frequency band	2.400 - 2.483/5.725 - 5.850 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum tilt angle	42 °
Maximum flight time	30 min
Maximum ascent speed	6 m/s
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.1 m
Horizontal hover accuracy	0.3 m
Maximum operating distance	7000 m
Built-in processor	-
Operating temperature (T-T)	0 - 40 °C
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1280 x 720, 1920 x 1080, 2720 x 1530, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1 \
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	84 °
Bitrate at maximum video resolution	100 Mbit/s
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
AC adapter power	100 W
AC adapter input voltage	17.4 V
Battery voltage	15.2 V
Battery capacity	5870 mAh

Weight and Dimensions

Battery weight	468 g
Weight (including battery)	1375 g
