dji PHANTOM 4 User Guide

EN
©
2018 DJI All Rights Reserved.
5
Updating the Firmware
DJI will release firmware updates when available. Refer to the official DJI
website and follow the instructions below to update the rmware.
1. Download the latest rmware update program from the ocial DJI website.
(http://www.dji.com/product/phantom-4/info#downloads)
2. Turn on the Charging Hub, then connect it to a computer using a Micro
USB cable.
3. Run the rmware update program. Press the update button and wait for
the process to nish.
4. The Charging Hub will automatically restart when the update has been
successfully completed.
5. Repeat this process if the rmware update fails for any reason.
Specications
Model PHANTOM 4 CHARGING HUB
Compatible Battery Charger Phantom 4 Charger (PH4C100)
Compatible Battery Model
PH4-5350mAh-15.2V
PH4-5870mAh-15.2V
Operating Temperature 41° to 104° F (5° to 40° C)
Operating Voltage 17.5 V
Weight 162 g

dji PHANTOM 4 Specifications

General

Product color	White
Frequency band	2.4 - 2.483 GHz
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	5000 m
Number of propeller blades	2
Moving control functions	Downward, Forward, Turn left, Turn right, Upward
Cables included	USB
Memory card included	MicroSD
Megapixel	12 MP
Video resolutions	1280 x 720, 1920 x 1080, 2704 x 1520, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Maximum video resolution	4096 x 2160 pixels
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	7.4 V
Battery capacity	6000 mAh

Weight and Dimensions

Width	289.5 mm
Height	196 mm
Weight	1380 g
