dji POCKET 2 User Manual

Not nal
4
©
2020 DJI OSMO All Rights Reserved.
DJI Pocket 2 User Manual
Introduction
DJI Pocket 2 is a handheld gimbal camera that combines mobility and stability in one device. It shoots sharp
64 MP photos and stable video at up to 4K 60fps. The onboard touchscreen displays a live view from the
camera and can control camera and gimbal movements. Create the perfect shot with intelligent modes such
as ActiceTrack, Zoom, Panorama, Timelapse, and HDR Video and enjoy high quality sound recording with four
microphones that boast wind noise reduction. Connect DJI Pocket 2 to DJI Mimo using a mobile device either
wirelessly* or by adapter. The app can be used to create professional-quality videos and to share to social
media instantly in Story mode.
Accessories such as the Mini Control Stick, Do-It-All Handle, Wireless Microphone Transmitter, Micro Tripod,
Tripod Mount (1/4”), and Wide-Angle Lens can be used to enjoy more DJI Pocket 2 features.
* The Do-It-All Handle is required in order to connect with DJI Mimo wirelessly.
Overview
1. Power Button
2. Lanyard Hole
3. Detachable Base
4. Microphone*
5. Touchscreen
6. Universal Port (with Cover)
7. Status LED
8. Shutter/Record Button
9. microSD Card Slot
10. USB-C Port
11. Function Button
12. Heat Dissipation Area
13. Pan Motor
14. Tilt Motor
15. Camera
16. Roll Motor
1
5
4
8
6
7
16
11
4
12
13
14
15
9
10
4
2
3
* For better audio quality, DO NOT block the microphone when recording video.

dji POCKET 2 Specifications

General

Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Supported video modes	1080p, 2160p
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum video resolution	3840 x 2160 pixels
Resolution at capture speed	1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@48fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 3840x2160@60fps
Megapixel	64 MP
Sensor type	CMOS
Optical sensor size	1/1.7 \
Image formats supported	JPEG, PNG
Maximum image resolution	9216 x 6912 pixels
ISO sensitivity	100, 6400
Image stabilizer	Yes
Field of view (FOV) angle	93 °
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	8 s
Number of axis	3
Mechanical pan range	-250 - 90 °
Mechanical roll range	-90 - 90 °
Mechanical tilt range	-180 - 70 °
Controllable pan range	-230 - 70 °
Angular vibration range	0 - 0.005 °
Controllable roll range	-45 - 45 °
Controllable tilt range	-100 - 50 °
Maximum controllable speed	120 °/sec
Product color	Black
Wi-Fi	No
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	256 GB
Battery voltage	7.7 V
Battery capacity	875 mAh
Operating voltage	8.8 V

Weight and Dimensions

Depth	38.1 mm
Width	30 mm
Height	124.7 mm
Weight	117 g
