dji RC Motion 2 User Manual

DJI RC Motion 2 User Manual
8
©
2023 DJI All Rights Reserved.
5V, 2A
If the battery level is low, it is recommended to use a charger that supports 5 V, 2 A output
to charge the device.
• Make sure that the default output voltage of the charger is 5 V. Excessive voltage
will damage the device.
The table below shows the battery level LED statuses during charging.
LEDs Battery Level
1%-50%
51%-75%
76%-99%
100%
Linking
Preparation before linking:
1. Power on the aircraft, goggles, and motion controller.
2. Open the goggles menu. Select
Status
and make sure that the aircraft model displayed
at the top of the menu is correct. Otherwise, select
Switch
from the upper right corner
of the menu and then select the correct aircraft.
3. Make sure the aircraft is linked with the goggles.
Link the aircraft with the motion controller:
5s
5s

dji RC Motion 2 Specifications

General

Brand	dji
Model	RC Motion 2
Category	Remote Control
Language	English
