dji SPARK User Guide

22
CHT
充電盒零組件
1. 充電盒開關
2. 電池指示燈
3. 充電盒電量指示燈
4. USB 連接埠
5. 電源連接埠
使用充電盒
外接交流電源進行充電
連接外部電源可為充電盒、智能飛行電池和行動裝置進行充電。請參照下列
步驟以連接並使用本產品：
6. 韌體升級連接埠 (Micro USB)
7. 保護蓋開關
8. 充電觸點
9. 充電導軌
10. 保護蓋
1
8
7
10
4
6
5
9
3
2
LED1 2 3 4

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
