dji SPARK User Guide

9
EN
3. Press the power button once, then again, and hold to turn on the station, or
connect it to a power source if its power level is too low (less than 5%).
4. Run the firmware update program. Press the update button and wait for the
process to nish.
5. The Charging Station will automatically restart when the update has been
successfully completed.
6. Repeat this process if, for any reason, the rmware update fails.
LED Display When Working Improperly
LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Item
LED4 blinks twice per
second
The station temperature
is too low
LED4 blinks three times
per second
The station temperature
is too high
You do not need to unplug and plug in the charger in the event of temperature error;
the charger will resume charging when the temperature is within the allowable range.
Updating Firmware
DJI will release rmware updates periodically. Refer to the ofcial DJI website and
follow the instructions below to update the rmware.
1. Download the latest rmware updating program from the ofcial DJI website.
(http://www.dji.com/spark/info#downloads)
2. Connect the station to a computer using a Micro USB cable.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
