dji SPARK User Guide

8
EN
Battery LED Indictors Description
Off Aircraft or battery is not placed or inserted correctly
Solid Yellow Prepared for charging
Flashes Yellow Waiting until the battery is ready for charging
Pulsing Green Charging
Solid Green The battery is fully charged
Solid Red Battery error
The four Charging Station power level LEDs indicate the current power level and
charging status of the station itself.
: LED is on : LED is ashing : LED is off
LED Display When Charging
LED1 LED2 LED3 LED4 Battery Level
0%~49%
50%~74%
75%~99%
The station is fully charged
LED Display When Checking the Battery Level
LED1 LED2 LED3 LED4 Battery Level
75%~100%
50%~74%
25%~49%
6%~24%
0%~5%

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
