dji spreading wings s900

Spreading Wings S900
User Manual
14
©
2014 DJI. All Rights Reserved.
Mounting Electronics and Wiring
If using a DJI WK-M ight controller, you must use the wires that came with the WK-M. M1 through
M6 correspond to each motor number.
Connecting the ight controller to the center frame
1. Connect the ight control system according to your ight control system user manual.
2. Plug in the connector sets to the ESC signal outlet on the center frame. Then plug in the connector set to
ight controller as shown below.
(1) Yellow 4-pin cables are for M1~ M4 connections. The yellow cable should be connected to M1.
(2) Brown 4-pin cables are for M5~ M6 connections. The brown cable should be connected to M5.
(3) Black 4-pin cables are for four continuous ground pins connections. M1~M4 are connected as the
following diagram shows.
M1
2
3
4
5
6
M
M
M
M
M
1
brown
2
3
M1
M2
M3
M4
M5
M6
yellow
1
2
3
M1
M2
M3
M4
M5
M6
yellow
brown
M1
2
3
4
5
6
M
M
M
M
M
M1
M2
M3
M4
M5
M6
3
1
4
2
5
6
4
6
3
5
2
1
the ESC Signal Outlet
the ESC Signal OutletWKM Flight Controller
A2 Flight Controller
