dji ZENMUSE P1 Quick Start Guide

7
EN
Operating Temperature Range -20° to 50° C (-4° to 122° F)
Storage Temperature Range -20° to 60° C (-4° to 140° F)
Absolute Accuracy Horizontal: 3 cm, Vertical: 5 cm
①
Camera
Sensor
Sensor size (still): 35.9×24 mm (full frame)
Sensor size (max video recording area): 34×19 mm
Eective pixels: 45 MP
Pixel size: 4.4 μm
Supported Lenses
DJI DL 24mm F2.8 LS ASPH Lens (ENTERPRISE) (with lens hood and
balancing ring/lter), FOV 84°
DJI DL 35mm F2.8 LS ASPH Lens (ENTERPRISE) (with lens hood and
balancing ring/lter), FOV 63.5°
DJI DL 50mm F2.8 LS ASPH Lens (ENTERPRISE) (with lens hood and
balancing ring/lter), FOV 46.8°
Supported SD Cards SD: UHS-Ⅰ rating or above; Max capacity: 512 GB
Storage Files Photo/Raw GNSS Observation Data/Image Log File
Photo Size 3:2 (8192×5460)
Operation Modes Photo, Video, Playback
Minimum Photo Interval 0.7 s
Shutter Speed
Mechanical Shutter Speed: 1/2000
②
-1 s
Electronic Shutter Speed: 1/8000-1 s
Aperture Range f/2.8-f/16
ISO Range
Photo: 100-25600
Video: 100-25600
Video Format MP4
Video Resolution
16:9
（
1920×1080
）
16:9
（
3840×2160
）
③
Frame Rate 60 fps
Gimbal
Stabilized System 3-axis (tilt, roll, pan)
Angular Vibration Range ±0.01°
Mount Detachable DJI SKYPORT

dji ZENMUSE P1 Specifications

General

Country of origin	China
Power consumption (max)	20 W
Product color	Black
Compatible products	DJI Matrice 300 RTK
International Protection (IP) code	IPX4
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	-20 - 60 %
Megapixel	45 MP
Maximum image resolution	8192 x 5460 pixels
ISO sensitivity	100, 25600
Image stabilizer	Yes
Maximum aperture number	16
Minimum aperture number	2.8
Field of view (FOV) angle	63.5 °
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	1 s
Compatible memory cards	SD
Maximum memory card size	512 GB
Maximum frame rate	60 fps
Video formats supported	MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Mechanical pan range	-320 - 320 °
Mechanical roll range	-55 - 55 °
Mechanical tilt range	-130 - 40 °
Wi-Fi	-

Weight and Dimensions

Depth	129 mm
Width	166 mm
Height	198 mm
Weight	800 g
