dji ZENMUSE P1 Quick Start Guide

8
EN
① Absolute accuracy measured with an aircraft with a GSD of 3 cm and flight speed of 15 m/s, with a
75% front overlap rate and a 55% side overlap rate.
② Aperture value no larger than f/5.6. The camera will automatically switch to the electronic shutter
when the shutter speed is larger than 1/10 s.
③ Only 35mm lens supported.
Controllable Range
Tilt: -125° to +40°
Roll: -55° to +55°
Pan: ±320°
This content is subject to change.
Download the latest version from
http://www.dji.com/zenmuse-p1
DJI is a trademark of DJI.
Copyright © 2020 DJI All Rights Reserved.

dji ZENMUSE P1 Specifications

General

Country of origin	China
Power consumption (max)	20 W
Product color	Black
Compatible products	DJI Matrice 300 RTK
International Protection (IP) code	IPX4
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	-20 - 60 %
Megapixel	45 MP
Maximum image resolution	8192 x 5460 pixels
ISO sensitivity	100, 25600
Image stabilizer	Yes
Maximum aperture number	16
Minimum aperture number	2.8
Field of view (FOV) angle	63.5 °
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	1 s
Compatible memory cards	SD
Maximum memory card size	512 GB
Maximum frame rate	60 fps
Video formats supported	MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Mechanical pan range	-320 - 320 °
Mechanical roll range	-55 - 55 °
Mechanical tilt range	-130 - 40 °
Wi-Fi	-

Weight and Dimensions

Depth	129 mm
Width	166 mm
Height	198 mm
Weight	800 g
