PARTII:FamiliarwiththeWoodChipper
It may be helpful to familiarize yourself with the controls and features of the Wood Chipper.
If you have any question, please contact the dealers in your area.

TECHNICALSPECIFICATIONS
 ElectricStart
Engine 14HPKOHLERCH440
Power GasolineMIDGRADE
ChipperCapacity 3(cuft/min/flowrate)
WoodDiameter diameter5INCHMAX
Permittedwoodwidth 7.75width1inchthick
Hydraulicpump 10ml/r,20mpa
Hydraulicmotor 0‐600rpm,MAX240N*M
OiltankCapacity 1.05GALSAW32HYDRAULIC
Tire 16*6.5‐8
OverallHeight 62INCHES
OverallLength 85INCHES
Width 33INCHES
weight 650LBS
CUTTERMaxRPM 2250
AUTO‐FEEDSPEEDBar:

Adjusttherotatingspeedofthefeedroller(from0‐600RPM).
AdjustRPMlowerforlargertreesandfasterforsmallertrees,astomatchcutterwheelcapacity.
