27
Appendix 3: Parts List
A. Welding parts
No. Description Qty No. Description Qty
A1 Main frame 1 A5 Incline bracket 1
A2 Base frame 1 A6 Filter bracket 1
A3L Left upright 1 A7 Running deck support tube 1
A3R Right upright 1 A11 Motor bracket 1
A4 Handrail 1 1
B. Plastic parts
No. Description Qty No. Description Qty
B1 Console set 1 B18 Silicon oil 1
B1-1 Overlay 1 B20 Round plug 1
B1-2 Membrane key 1 B21 Squared shape plug 4
B1-3 Console housing 1 B22 Motor left side cover 1
B1-5 Tablet holder 1 B23 Motor right side cover 1
B2 Console cover 1 B26 Deck cushion 2
B3 Protecting foam 2 B27 New cushion 4
B4 Handrail plug 2 B31 Rubber pad 2
B5 Console back cover 1 B34 EVA pad(for tablet holder) 1
B6 Transporting wheel cover 2 B44 EVA pad 1
B8 Flat foot pad 2 B45 Console housing back cover 1
B9 U shaped foot pad 2 B49 Bottle holder 2
B10 Limited cushion 2 B52 Side rail cover 2
B13 Motor upper cover 1 B58 Handle bar cover 2
B15 Side rail 2 B59 Handle bar plug cover 2
B16L Left end cap
1 B60 Anti-slippery pad 4
B16R Right end cap 1 B65L Console left side cover 1
B17 Adjusting wheel 4 B65R Console right side cover 1
C. Electronic parts
No. Description Qty No. Description Qty
C1 DC Motor 1 C15 Power cable 1
C2 Running belt 1 C16 Upper wire 1
C3 Rear roller 1 C17 Lower wire 1
C4 Front roller 1 C20 Magnetic ring 1
C5 Running board 1 C21 Induction 1
C6 Cylinder 1 C22 Filter 1
C7 Motor belt 1 C23 Overload protector 1
C8 Power switch 1 C27 Single cord(black) 1
C9 Controller 1 C29 Hand pulse 2
C10 Left quick button 1 C31 Single cord(red) 2
C11 Right quick button 1 C32 Single cord(black) 1
