DLA 32
Dwg
Key #
Part Description
03180-01105
1
Cylinder Head, 32 / 64 cc STRAIGHT PLUG Conf.
03180-01106
2
Crankshaft & Connecting Rod, 3cc
03180-01107
3
Crank Case, Front & Rear, 32cc
03180-01108
4
Piston, 32 / 64 / 128cc
03180-01109
5
Ring, Piston, 32 / 64 / 128cc
03180-01110
6
Ignition Module, Capacitive Discharge., 32cc
03180-01111
7
Muffler,Can - Std, 32cc
03180-01112
8
Carburetor, 32cc, Complete, Tillotson HU-34A, 32cc
03180-01113
9
Standoffs, Engine Mounting, & Bolts, 32cc
03180-01114
10
Spark Plug, Iridium, (All DLA Engines)
03180-01115
11
Reed Valve Assembly, Carburetor, 32cc
03180-01116
12
Bearing Set, Front & Rear, Crankshaft (FAG), 32cc
03180-01117
13
Sensor, Ignition, w/mounting screws, (ALL DLA Engines)
03180-01118
14
Gasket Set, Muffler, Carburetor, Head, 32cc
03180-01119
15
Bolt Set: Mounting, Muffler, Prop, 32cc
03180-01120
16
Hub, Propeller, Washer, Propeller, 32cc
03180-01121
17
Bearing Needle, Connecting-rod wrist-pin, 32 / 64cc, 12mm (IKO Bearing, Japan)
03180-01122
18
Wrist-Pin, Piston, Con-rod, 32 / 64cc
03180-01123
19
Puffer - Line, Carb to Reed Valve Assembly
03180-01124
20
Bushing-Spacer, Crankshaft, forward
03180-01125
21
Propeller Shaft, Crankshaft Extension, 32cc
03180-01126 22 Retainers, Piston Pin, 32cc
03180-01127 1S Cylinder Head, 32 / 64 cc SLANTED PLUG Conf.
03180-01128 5B
Rings, BOWMAN 32,64, 128cc
03180-01129 Rerserved
03180-01130 Gasket, Cylinder Head
03180-01131 Gasket, Carburetor, 32cc
03180-01132 Rerserved
03180-01133 Key, Woodruff, 32cc
03180-01134 Gasket, Muffler, 32cc
03180-01135 Prop Shaft, Extension, 32cc
03180-01136 Prop Washer, Only, 32cc
03180-01137 Prop-Hub (Only), 32cc
03180-01138 Bolts, Muffler, (All DLA Engines)
03180-01139 Reed Values, Only, 32cc
01380-01106
Muffler, Pitts Style, DLA 32cc
01380-01145 Air Fiflter, Velocity Stack, (All DLA Engines)
01380-01239
Tachometer, (All DLA Engines)
01380-01240
Gasket,MUFFLER< New Style, & Bolts / Lock washers, 32 / 64cccc
01380-01140 Carburetor Gasket & Diaphragm Kit (DG-11HU), for Tillotson HU-134A Carb, 32cc
01380-01141 Carburetor, Rer-build Kit Completes (RK-31HU) for Titllotson HU-134A Carb, 32cc
01380-01142
Muffler, CANISTER, Includes: Muffler, Header, and couples (1 each), 32 & 64cc
03180-01143
Gasket, Muffler, Paper (original) with Bolts and Lockwashers
Part Numbers - Engine Components
DLA 32cc PARTS LIST - Rev: A.06
