Tech Specs
FM TRANSMITTER
Modulation: FM Stereo
RF Output Frequency Range: 88.1 - 107.9 MHz
Default Preset Frequencies (MHz): 88.1, 94.9, 100.9, and 107.9
Frequency Adjustment: 0.1 MHz per step
Frequency Response: 50Hz ~ 18KHz
Transmitter Range: Up to 27 feet (8.2M)
Tuning: Digitally controlled crystal oscillator
International frequency compatible
DOCK CONNECTOR
USB to Sansa Dock Connector Cable: Length 48”
Aux Input Jack: 3.5mm Stereo Mini jack
Direct Output: 3.5mm Stereo Mini jack
POWER
USB Output: 500mA @ 5VDC (for charging external devices)
Input Voltage: 12 – 16 VDC
Input Current: <300mA @ DC12V~16V
CONNECTORS
Auxiliary Input Jack: 3.5mm Stereo mini jack
Direct Output: 3.5mm Stereo mini jack
TEMPERATURE
Storage Temperature: -10° to 120° F (-23° to 49° C)
Operating Temperature: -4° to 113° F (-20° to 45° C)
Service + Support
For more information and tips, please visit our website at www.dlo.com and
click Support.
