Specifications
We follow a policy of continuous advancement in
development.
For this reason all or part of specifications & designs
may be changed without prior notice.
11
DLS CLASSIC RA25 RA30
Number of channels 2 3
Working mode AB AB
Power output at 13,8 Volt, 20 Hz - 20 kHz, max 0,1 % THD, all channels driven.
Power output, 4 ohm 2 x 70 W 2 x 70 W + 1 x 265 W
Power output, 2 ohm 2 x 110 W 2 x 100 W + 1 x 365 W
Power output, 4 ohm bridged 1 x 220 W -
THD @1 W < 0,1% < 0,1%
Signal to noise ratio, A-weighted >100 dB >100 dB
Damping factor >200 >200
Frequency response +/- 0,5 dB 10 Hz - 50 kHz 10 Hz - 50 kHz
Input impedance, low level >10 kohm >10 kohm
Input impedance, high level 330 ohm 330 ohm
High level input with auto start Yes Yes
Input sensitivity 0,2 - 7V 0,2 - 7V
Filter slope 12 dB/octave 12 dB/octave
Pre amp configuration on Front channel:
Filter high pass 20 - 150 Hz* 45 - 125 Hz*
* can be switched in/out
Pre amp configuration onRA30 sub channel:
Filter lowpass - 40 - 125 Hz
Fixed 25 Hz subsonic filter - Yes*
Phase shift 0- 180 degrees contiously - Yes
Grand bass adjustable gain @ 40 Hz - 0 - +18 dB
Remote bass level and phase control - Yes
* can be switched in/out
Protection current & thermal current & thermal
Max cable size, DC input 7 AWG, 10 mm
2
4 AWG, 21 mm
2
Max cable size, front speakers 7 AWG, 10 mm
2
10 AWG, 6 mm
2
Max cable size, sub output 7 AWG, 10 mm
2
Power consumption:
Idle 0,6 A 0,9 A
Maximum 25 A 70 A
Fuse 25 A 2 x 35 A
Dimensions HxWxD(mm) 59x247x245 59x385x245
Dimensions (inch) 2,33x9,72x9,65 2,33x15,15x9,65
Weight 2,6 kg (5,7 lbs) 4,4 kg (9,7 lbs)
RA25 & RA30
NOTE!
The amplifiers are two (2) ohm stable. In stereo
mode it´s possible to load the amplifier down to two
ohm on each channel.
In mono bridge mode it´s possible to load with one
four ohm fullrange speaker or subwoofer.
The sub channel on RA30 can handle 2 ohm loads,
for example two 4 ohm subwoofers in parallel.
In bridge mode connection an amplifier sees a four
ohm speaker as a two ohm load.
