DMEGA Mega-Air 2 - Specification of equipment; Dimension of the equipment

- 11 -
4.2 Specification of equipment
(1) Compressed air method: Piston-Wob-L type
(2) Response quantity of dental unit chair: 3~4unit
(3) Main voltage: 220~230V
(4) Frequency: 50/60Hz
(5) Electrical power (Motor): 1.5KW (2HP)
(6) Air tank volume: 40 liter
(7) Pressure setting: 5~8bar (0.5~0.8MPa)
Insulation diagram
4.3 Dimension of the equipment
Dimension
630(L) x 450(W) x 820(H) mm
Weight
52kg±0.5
