- 8 -
2.6 Environmental Conditions for normal operation
- Temperature: 10°C ~35°C
- Humidity: 30% to 80% R.H.
- Atmospheric pressure: 700 to 1,060 hPa
2.7 Transport and storage conditions
The compressor is packed in a special transport carton for shipping. This serves to
protect the appliance from damage during transport.
Be sure to set the compressor in an upright position during transport.
Protect the compressor during transport and storage from humidity, dirt and extremes
of temperature. Compressors which are still in their original packing can be safely
stored in warm, dry and dust-free rooms.
- Temperature: 0 to 50 ºC
- Relative Humidity: 25 to 80 % R.H.
- Atmospheric Pressure: 700 to 1,060 hPa
----------------------------------------- -----------------------------------------
The compressor may only be transported when no pressure is present.
Before transport the pressure tank and the pressure hose must be vented thoroughly.
