Parameter Description Navigation Values
Default
Value
Re-levelling
Not present: No Re-levelling
Type 1: (open or close door). This setting is
indicated for traction installations for good
stopping accuracy. Re-levelling is triggered when
the elevator car leaves its position "perfectally at
floor” that’s to say when one of the two beams
interrupted. Re-levelling ends when both beams
are free. WARNING: this setting is not suitable
for hydraulic installations due to the risk of
"pumping" effect (elevator car drifts down after
stopping)
Type 2: (open or close door). This setting is
indicated for hydraulic installations and operates
as in Type 1, except that the two beams must be
interrupted before the re-levelling starts. Re-
levelling ends when the two beams are free.
WARNING: the use of sensors with reduced
distance between beams (TMS03 = 20 mm) is
suggested.
Type 3: Levelling 1 beam open door 2 beams
closed door. This setting allows the levelling 1
beam, floor door open (elevator car light on) and
levelling 2 beams, floor door closed (elevator car
light off). WARNING: to operate the levelling door
open, no matter which option you have chosen, it
is necessary to shunt the door safety, using an
approved system.
Note: with the Encoder positioning system,
distance of activation of the re-levelling is
displayed
◄► (Choice)
Not present
Type 1
Type 2
Type 3
Not
present
Main floor
Position of the main floor (all calls below this floor
are served only upwards (only down collective)
▲▼
(Increase/Decrease)
0 <-> Floor
No.
0
Low Speed
fault time
Time before activation of the Low Speed fault
(low speed too long)
▲▼
(Increase/Decrease)
7 s <-> 40 s 7 s
Running time Time before activation of running time fault
▲▼
(Increase/Decrease)
20 s <-> 45
s
20 s
Type of
Installation
Type of installation (Simplex / Multiplex) ◄► (Choice)
Simplex;
Multiplex
Simplex
Multiplex
configuration
Multiplex configuration: Lift No.(LN); Push-
Buttons Line (PBL); Floors in multiplex; Offset.
For description, refer to Annex I.
◄► (Select
parameter)
▲▼ (Change value)
- Lift No
(LN).: 1<->4
-
PushButtons
Line (PBL):
0(1 Line)<-
>3(4 Lines)
(LN).
(PBL):
1.0
