DMG RAFFAELLO Installation Manual

D I S P L A Y
16
4,3" / 5"4,3" / 5"4,3" / 5"
Collegamento SENSORE POSIZIONE INDIPENDENTE (OPTION)
INDEPENDENT FLOOR DETECTION wiring (OPTION)
Branchements capteur position indépendant • Anschlüsse mit separatem Positionssensor
Conexiones de posición independiente
Sensori magnetici NC
NC magnetic sensors
AUT.KIT08
AUT.KIT16
Cod.
8 piani / 8 floors
16 piani / 16 floors
Cod.
A
B
Min. 90 mm
TETTO CABINA / TOP OF CAR
D =
Min. 150 mm
400 mm (V <= 0,5 m/s)
800 mm (V <= 1,0 m/s)
960 mm (V <= 1,2 m/s )MAX
CABINA AL PIANO X
CAR AT FLOOR X
3ª calamita al PIANO PRINCIPALE
(piano di reset conteggio)
3rd magnet at MAIN FLOOR
(counting reset floor)
Pos. Sensor (Auto)
Frecce pilotate da sensori
Arrows piloted by sensors
Pos. Sensor (Manual)
Frecce pilotate da ingressi
Arrows piloted by inputs
3.5
SOLO / ONLYSOLO / ONLY
Manual SensorManual Sensor
SOLO / ONLY
Manual Sensor
12/24V DC
Frecce
Arrows
Impostazione protocollo • Protocol setting
PRG
Input
Pos. Sensor (Manual)
PRG ADV
Pos. Sensor (Auto)
D
E
Impostazione comune ingressi (NEGATIVO) • Inputs common setting (NEGATIVE)
D
PRG
Options
Interface Options
Common Selection
Negative
PRG ADV
C
X01
PARALLEL INPUT
X02
X03
X04
X05
X06
X07
X08
X09
X10
UP
UP
DOWN
DOWN
1
PRG ADV
S2
S1
S3
TRIGGER
FAIL/RUN
POWER
SUPPLY
S4
LOP COP
12/24 Vdc
COP LIP/LOP
S1
S2
S3
CAR HERE
CUSTOM
max 73 piani (-9, 0, 63)
max 73 floors (-9, 0, 63)
maxi 73 niveaux (-9, 0, 63)
max. 73 Etagen (-9, 0, 63)
máx 73 pisos (-9, 0, 63)
DK_RS_00M
DK__S100M
Impostazione display in cabina (COP) • Car (COP) position indicator setting
§ 3.2
SOLO come display di CABINA
CAR position indicator ONLY
