DNP CX-D80DR - Page 40

1-40 (No.HD003<Rev.004>)
>>Information> >>>Firmware
>>>HR-T POT
[ENTER]
[EXIT]
>>>Total Count
>>>HR-T Temp
>>>HR-B Temp
[NEXT]
[NEXT]
[NEXT]
[NEXT]
>>>HR-B POT Rst
>>>HR-B POT
>>>HR-T POT Rst
[NEXT]
[NEXT]
[NEXT]
4
>Laminator>
>>Maintenance>
[ENTER]
[EXIT]
[NEXT]
>>>Card Pos
>>>EM Snsr-B Lvl
[ENTER]
[EXIT]
>>>PM Snsr-T Lvl
>>>PM Snsr-B Lvl
>>>EM Snsr-T Lvl
[NEXT]
[NEXT]
[NEXT]
[NEXT]
>>User Mode>
[NEXT]
>>>Mode
>>>Film-B Pos
[ENTER]
[EXIT]
>>>Film-T
>>>Film-B
>>>Film-T Pos
[NEXT]
[NEXT]
[NEXT]
[NEXT]
>>>Cooling Time
>>>HR-T Temp
>>>HR-B Temp
>>>Speed
[NEXT]
[NEXT]
[NEXT]
[NEXT]
Select operational mode
[Laminate, Pass]
Select with [ ] and save with [ ].
Select film used with upper cassette
[Patch, Overlay]
Select with [ ] and save with [ ].
Select film used with lower cassette
[Patch, Overlay]
Select with [ ] and save with [ ].
Patch position setting of film traveling direction
[-7 ~ -1,0,+1 ~ +7]
Select with [ ] and save with [ ].
Patch position setting of film traveling direction
[-7 ~ -1,0,+1 ~ +7]
Select with [ ] and save with [ ].
Setting of the heating roller temperature
[90 ~ 180
O
C] (Different according to the version of the firmware.)
Select with [ ] and save with [ ].
Setting of the heating roller temperature
[90 ~ 180
O
C] (Different according to the version of the firmware.)
Select with [ ] and save with [ ].
Setting of the card transportation speed at lamination
[3 ~ 12 mm/s]
Select with [ ] and save with [ ].
Setting of card cooling standby time before lamination
[0, 5, 7, 10, 15, 20, 30 sec]
Select with [ ] and save with [ ].
Setting of the card stop position X
[-7(Left) ~ -1(Left),0,+1(Right) ~ +7(Right)]
Select with [ ] and save with [ ].
Adjust the threshold level of the Marker Sensor T
[1 ~ 10]
Select with [ ] and save with [ ].
Adjust the threshold level of the Marker Sensor B
[1 ~ 10]
Select with [ ] and save with [ ].
Adjust the threshold level of the End Sensor T
[1 ~ 10]
Select with [ ] and save with [ ].
Adjust the threshold level of the End Sensor B
[1 ~ 10]
Select with [ ] and save with [ ].
Laminator Firmware version
Laminator Total Counter
Laminator Heater-T Temperature
Laminator Heater-B Temperature
Laminator Heater-T Power on time
Laminator Heater-B Power on time
Laminator Heater-T Power on time Reset
Laminator Heater-B Power on time Reset
