Trailer Hitch Classification
Class III - Heavy Duty 5,000 lbs (2 268 kg)
Class IV - Extra
Heavy Duty
10,000 lbs (4 540 kg)
All trailer hitches should be professionally installed on
your vehicle.
Trailer Towing Weights (Maximum Trailer Weight
Ratings)
The following chart provides the maximum trailer
weight ratings towable for your given drivetrain.
Engine/Transmission GCWR (Gross Com-
bined Wt. Rating)
Frontal Area Max. GTW (Gross
Trailer Wt.)
Max. Tongue Wt.
2.4L Automatic 5,200 lbs (2358 kg) 40 SQ. FT. (3.72
square meters)
Up to 2 persons &
Luggage 850 lbs (385
kg)
85 lbs (39 kg)
5,200 lbs (2358 kg) 40 SQ. FT. (3.72
square meters)
3 to 5 persons &
Luggage 400 lbs (181
kg)
40 lbs (18 kg)
5,200 lbs (2358 kg) 40 SQ. FT. (3.72
square meters)
6 to 7 persons &
Luggage Not Recom-
mended
N/A
372 STARTING AND OPERATING
