Cavity Mini Fuse Description
F21 25 Amp
Natural
Anti-Lock Brake System
(ABS) Module
F23 10 Amp Red Ignition Switch
F24 20 Amp Yel-
low
Hazard
F26 20 Amp Yel-
low
Stop Lamp
F33 15 Amp Blue Front/Rear Washer
20 Amp Yel-
low
Spare (IOD)
CAUTION!
•
When installing the Integrated Power Module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Integrated Power
Module, and possibly result in a electrical system
failure.
•
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
454 MAINTAINING YOUR VEHICLE
