Dodge 2011 Nitro - Page 436

Cavity Cartridge
Fuse
Mini-
Fuse
Description
J4 25 Amp
Natural
Driver Door Node
J5 25 Amp
Natural
Passenger Door Node
J6 40 Amp
Green
Antilock Brakes
Pump, Stability
Control System
J7 30 Amp
Pink
Antilock Brakes
Valve, Stability
Control System
J8 40 Amp
Green
Power Seat – If
Equipped
J9 — —
J10 — —
J11 30 Amp
Pink
Anti–Theft Module
Lock-Unlock
Cavity Cartridge
Fuse
Mini-
Fuse
Description
J12 — —
J13 60 Amp
Yellow
Ignition Off Draw –
Main
J14 40 Amp
Green
Rear Defroster
J15 40 Amp
Green
Front Blower
J17 40 Amp
Green
Starter Solenoid
J18 20 Amp
Blue
Powertrain Control
Module
J19 60 Amp
Yellow
Radiator Fan
J20 30 Amp
Pink
Front Wiper
7
MAINTAINING YOUR VEHICLE 433
