Cavity Cartridge
Fuse
Mini-
Fuse
Description
M33 10 Amp
Red
Powertrain Control
Module
M34 10 Amp
Red
Park Assist/Rear
Camera, Climate Con-
trol System Module,
Headlamp Wash,
Compass, IR Sensor,
Relay Diesel Cabin
Heater, Radiator Fan
Diesel – If Equipped
M35 10 Amp
Red
Heated Mirrors – If
Equipped
M36 — —
Cavity Cartridge
Fuse
Mini-
Fuse
Description
M37 10 Amp
Red
Antilock Brakes, Sta-
bility Control System,
Stop Lamp Switch,
Fuel Pump Relay
M38 25 Amp
Natural
Door and Liftgate
Lock/Unlock Motors
CAUTION!
•
When installing the integrated power module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the integrated power
module, and possibly result in a electrical system
failure.
(Continued)
7
MAINTAINING YOUR VEHICLE 437
