SERVICING AND MAINTENANCE 319
(Continued)
F95 – 10 Amp Red Rear Camera / Blind Spot Sensor *
F96 – 10 Amp Red Rear Seat Heater Switch*
F97 – 20 Amp Yellow Rear Heated Seats/Heated Steering Wheel*
F98 – 20 Amp Yellow Ventilated Seats/Front Heated Seats*
F99 – 10 Amp Red Climate Control/Driver Assistance Systems Module/HALF/Parktronx
F100 – 10 Amp Red Active Damping*
F101 – 15 Amp Blue ECCM/SMRT HI-Beams*
F102 – 15 Amp Blue Spare
F103 – 10 Amp Red PTC/Rear HVAC *
F104 – 20 Amp Yellow Power Outlets (Instrument Panel/Center Console/Rear Cargo
* If Equipped
Cavity Cartridge Fuse Micro Fuse Description
CAUTION!
When installing the power distribution
center cover, it is important to ensure the
cover is properly positioned and fully
latched. Failure to do so may allow water to
get into the power distribution center and
possibly result in an electrical system
failure.
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse
continues to blow, it indicates a problem in the
circuit that must be corrected.
CAUTION! (Continued)
8
