104 SERVICING AND MAINTENANCE
F32 20 Amp Blue – ECM / PCM
F33 30 Amp Pink – Brake Vacuum Pump
F34 – – Spare
F35 – 10 Amp Red
PCM / ECM / Power Pack Unit (PPU) Motor Generator Unit
(MGU) Wake Up / EPS / Active Tuned Mass Module
(ATMM) / ESP
F36 – – Spare
F37 – 5 Amp Tan R / S Output to iPDC
F38 – 10 Amp Red DTCM / Active CL TEMP VLV
F39 – 15 Amp Red MOD ATMM
F40 40 Amp Green – Starter
F41 – 10 Amp Red IRCAM Heaters
F42 20 Amp Blue – AUX SWITCH #5 – If Equipped
F43 – 20 Amp Yellow MGU Coolant Pump / ADCM
F44 – 10 Amp Red Trailer Camera
F45 – 10 Amp Red ADCM – If Equipped
F46 30 Amp Pink – Fuel Heater
F47 30 Amp Pink – Rear Defroster
F48 – – Spare
F49 30 Amp Pink – Heater Control
F50 20 Amp Blue – AUX SWITCH #6 — If Equipped
Cavity Cartridge Fuse Micro Fuse Description
