SERVICING AND MAINTENANCE 105
F51 25 Amp White – FUEL PUMP MOTOR #1 — If Equipped
F52 – – Spare
F53 – 10 Amp Red Supply / Purging Pump
F54 – 15 Amp Blue PCM
F55 – 15 Amp Blue Right HID Headlamp
F56 – – Spare
F57 – 20 Amp Yellow Horn
F58 25 Amp White – FUEL PUMP MOTOR #2 — If Equipped
F59 – 25 Amp Clear Injectors / IGN Coil / Glow Plug Module
F60 – 20 Amp Yellow ECM / PCM / ACT Short Running Valve / LTR Cool Pump
F61 – 15 Amp Blue Left HID Headlamp
F62 60 Amp Blue – LTR Coolant Pump (TRX) / Glow Plug (Diesel)
F63 20 Amp Blue – NOx Sensor #1/#2
F64 – 10 Amp Red PM Sensor
Cavity Cartridge Fuse Micro Fuse Description
CAUTION!
When installing the power distribution center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may
allow water to get into the power distribution center and possibly result in an electrical system failure.
When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indi-
cated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must
be corrected.
8
