106 SERVICING AND MAINTENANCE
Internal Power Distribution Center
The Power Distribution Center is located under the drivers side instrument panel. This center contains cartridge fuses, micro fuses, relays, and circuit
breakers. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the
inside cover that corresponds to the following chart.
Cavity Cartridge Fuse Micro Fuse Description
F01 30 Amp Pink – ASSY Trailer Tow Receptacle Fuse B+
F03 – 20 Amp Yellow Module Seat Heater Front (Pass)
F04 – – —
F05 – 20 Amp Yellow Module PPU Cooling Fan
F06 40 Amp Green – —
F07 40 Amp Green – Mod CBC 3 PWR Locks
F08 – – —
F09 – – —
F10 40 Amp Green – HVAC Blower Motor
F11 – 5 Amp Tan
Output to Under-hood Power Distribution Center (UPDC)
Run Coil
F12 – 25 Amp Clear
Mod Audio Amplifier / Active Noise Cancellation / SW
Inverter
F13 – 20 Amp Yellow Mod Seat Heater Front (Driver)
F14 – 15 Amp Blue Mod Seat Heater Front (Steering Wheel)
F15 – – —
F16 – – —
