Dodge VIPER 2013 - Fuses

FUSES
Integrated Power Module
• The Integrated Power Module (fuses) is located in the engine compartment on the right
hand side near the Brake/Clutch Fluid Reservoir. This module contains fuses and
relays.
Cavity Relay Cartridge
Fuse
Mini-Fuse Micro-Fuse Description
3 — 40 Amp
Green
— — Rad Fan
4 — 40 Amp
Green
— — Rad Fan Rly High
5 — 40 Amp
Green
— — ABS/ESP Pump Feed
6 — 40 Amp
Green
— — Starter
7 — 40 Amp
Green
— — CBC (Ext. Lighting #1)
8 — 40 Amp
Green
— — CBC (Ext. Lighting #2)
9 — 30 Amp
Pink
— — CBC (Int. Liggting, washer)
10 — — — — b+ Jumper
11 — — 20 Amp
Yellow
— Auto Shutdown Relay (ASD)
12 — 25 Amp
Natural
— — ABS/ESP Valve Feed
13 — — 20 Amp
Yellow
— Horn
14 — — 10 Amp
Red
— A/C Clutch
15 — — 10 Amp
Red
— Diagnostic, Mirror , Fuel Door , Stop
Switch
16 — — 15 Amp
Blue
— KIN,RFHub
17 — — 15 Amp
Blue
— Power Seats
18 — 30 Amp
Pink
— — Driver Door Mod
19 — 30 Amp
Pink
— — Passenger Door Mod
20 — 30 Amp
Pink
— — EBL
21 — 20 Amp
Blue
— — Wiper
