Dodge VIPER 2013 - Page 89

Cavity Relay Cartridge
Fuse
Mini-Fuse Micro-Fuse Description
22 — — — — B+ Jumper
23 — — 15 Amp
Blue
— HVAC Module, Cluster , ICS Switch
Bank
24 — — 25 Amp
Natural
— PCM- Power Control Module
25 — — 25 Amp
Natural
— Fuel Pump
26 — — 20 Amp
Yellow
— ASD #1
27 — — 20 Amp
Yellow
— ASD #2
28 — — — — Spare
29 — 40 Amp
Green
— — HV AC Blower
30 — 20 Amp
Yellow
— — RR Power Outlet, Adj. Pedals, UCI
31 — — — — B+ Jumper
32 — — — — B+ Jumper
33 — 20 Amp
Yellow
— — Run ACCY #1
34 — — — — B+ Jumper
35 — — — — Spare
36 — — 10 Amp
Red
— ORC Mod Run
37 — — 15 Amp
Blue
— Cluster , Mirror , Camera
38 — — 20 Amp
Yellow
— Active Damping Suspension
39 — — 10 Amp
Red
— HVAC Module, In Car Temp
40 — — 15 Amp
Blue
— Radio
41 G8V A — — — Run/Start
42 G8V A — — — Fuel Door
43AC — — 10 Amp
Red
— SCCM
43BE — — 10 Amp
Red
— Corax
44BE — — 10 Amp
Red
—IBS
45 — — 10 Amp
Red
— PCM- Powertrain Control Module
