Dodge VIPER 2013 - Page 90

Cavity Relay Cartridge
Fuse
Mini-Fuse Micro-Fuse Description
46 — — 10 Amp
Red
— ESP Module
47 — — 10 Amp
Red
— ORC Module
48 — — 10 Amp
Red
— SCCM
49 — — 25 Amp
Natural
— Amplifier
50 — — — HC Micro Rad Fan
51 — — — HC Micro Rad Fan Relay SER/PAR
52 — — — HC Micro Starter Relay
53 — — — HC Micro EBL Relay
54 HC
Relay
— — — Rad Fan Relay High
55 — — — HC Micro W iper ON/OFF
56 — — — HC Micro W iper LO/HI
57 G8V A — — — Horn Relay
58 G8V A — — — A/C Clutch Relay
59 — — — HC Micro HVAC Blower
60 — — — HC Micro Fuel Pump
61 G8V A — — — Run Relay #1
62 G8V A — — — Run Relay #2
63 — — — HC Micro ASD #1
64 — — — HC Micro ASD #2
65 G8V A — — — Run Accy #1, Pop Up
