Introduction
Dark EnerGy
DOEPFER
1.2. Preparations
WhenyourstputDarkEnergyoutofthebox,pleasecheckifeverythingiscomplete.Youwillndthe
followingcomponentsinthebox:
•DarkEnergySynthesizer
•Poweradapter12-15V AC/min. 400mA
•Instrumentcabelwith3,5mmand1/4“plugs
•USBcabel(A-Btype)
•TwoA-100patchcabels
•Thisownersmanual
You will also need:
•Asuitableaudiosystem(mixer,amplier,speakerorkeyboardamp)
TorunDarkEnergyviaMIDI-DINsocketyouwillalsoneed:
•AMIDIcabletoconnectsuitableaMIDIcontrollingdevice/keyboard/computerandDarkEnergy.
•AMIDI-keyboardand/orcomputerwithsuitableMIDIsequencerapplication
TorunDarkEnergyviaCV/Gateconnectionsyouwillalsoneed:
•Atleasttwo3,5mmplugpatchcabelsandasuitablesequencer(e.g.theDoepfersequencermodule
A-155)oraCV/Gatekeyboard(e.g.theDoepfermodelA-100).
Setup:
UseDarkEnergyinalyingorstandupposition.Pleaseuseasuitablesupport.Thewoodensidepanelscan
bedismantledinordertoconnecttwoormoreunitsmechnicallytoonebigdevice.Moreinformationonthis
canbefoundlaterinthismanual.
Connections:
TorunDarkEnergy,youdonotneednecessarilyallit‘sbuiltinsockets.Forabasicsetup,youwillneedjust
theonesshowninthepicturebelow.Makeuseoftheadditionalconnectionfacilitiesandyouwillexpand
DarkEnergy‘ssoniccapabilitiesalot.Theywillbedescribedtogetherwiththecorrespondingmoduleslater
on in this manual.
