Instructions manual / GX Screwdrivers
6
3. Electric specification
Items Power controller Screwdriver
Model XS-40D
GX150, GX220, GX450,
GX150P, GX220P, GX450P
Input 110 / 230VAC (selectable) DC40V
Output 30/40VDC ( selectable )
Rated power 2.5A 95W
Maximum output current 8 A
Intermittent operation 10s On / 30s Off
Safety system CE certified ( Class I ) Class III
4. Mechanical specification of XS-40D
Size : 98 x 158 x 55H (mm)
Weight : 850gr
Power cord : 1.5 m
Fuse : 10 A 250V
5. INPUT Power select
By replacing the position of cover as below, the input power can be selected for 110V or 230V.
