Dogtra 620NCP - Page 23

42
DESCRIPTION OF TRANSMITTER PARTS
transmitter (2-dog)
Antenna
Nick/Cont.
Toggle Switch
Battery Charging
Receptacle &
Rubber Plug
ON/OFF
Maganetic Red Dot
1
st
-dog
Pager
(Gray Button)
2
nd
-dog
Pager
(Orange Button)
ON/OFF
Switch
LCD Screen
Rheostat
Intensity Dial
Indicator Light
(LED Window)
1
st
-dog
Nick & Cont.
(Gray Button)
2
nd
-dog
Nick & Cont.
(Orange Button)
43
DESCRIPTION OF TRANSMITTER PARTS
Transmitter Antenna
A short 5cm antenna is supplied with the
transmitter.
The antenna must be fastened to the transmitter
before using the unit.
